Setting the Display of the Visual Information Bar

The Visual Information Bar displays various lighting patterns according to the beat of the metronome, the touch strength (velocity) when playing the keyboard, and the depth to which the damper pedal is pressed.

Changing Display Settings

The lighting pattern of the Visual Information Bar changes depending on the display settings.

While holding down the “FUNCTION” button, press one of the F5 to A5 keys.

Selecting a Setting Value Directly (operation type A)

Default value: Auto
When the display is set to a setting other than <Auto>, it will light up only when the action or operation of the selected setting is performed.

Key	Display Settings	Setting Details
F5	Auto	The display automatically changes in response to your performance and operations on the Digital Piano.
F{5	Metronome	Lights up to the beat only when the metronome is playing. Lighting patterns can be switched.
G5	Keyboard	Lights up in response to touch strength (velocity) when the keys are played or according to the velocity of the song playing on the Digital Piano.
A}5	Pedal	Lights up in response to the depth to which the damper pedal is pressed.
A5	Audio	Lights up in response to the wireless audio input signal. Lighting patterns can be switched.

For the following operations, the Visual Information Bar lights up regardless of display settings.

During demo song playback: Lights up in response to the velocity of the song.
While making various settings using the keyboard: The set value or approximate value lights up.
During Instant RePlayer playback: Lights up to indicate where the current playback position is in the overall recording.
When connected to CASIO MUSIC SPACE and using the “Live Concert Simulator” feature: Lights up in response to audio input from the app.

Switching Lighting Patterns

When the display settings are <Metronome> and <Audio>, you can switch the lighting pattern.

Metronome Type

The Visual Information Bar displays the beat in time with the metronome beat. You can choose from five types of beat display using the [Metronome Type] setting.

While holding down the “FUNCTION” button, press the B}5 key (Metronome Type).

Switching On/Off or Changing Setting Values Using a Single Key (operation type D)

Audio Illumination Type

The Visual Information Bar blinks in time with the wireless audio input signal, allowing you to enjoy the illumination display. The [Audio Illumination Type] setting allows you to select from four types of illumination display.

While holding down the “FUNCTION” button, press the B5 key (Audio Illumination Type).

Switching On/Off or Changing Setting Values Using a Single Key (operation type D)

Brightness Setting and No Lighting

If the brightness of the Visual Information Bar is a little too bright, you can reduce the brightness or turn it off.

While holding down the “FUNCTION” button, press the C6 key (Brightness/Off).

Switching On/Off or Changing Setting Values Using a Single Key (operation type D)

Default value: 2

Setting Value	Notification Tone	Setting Details
Off	Tone for Off	Turns off the Visual Information Bar.
1	1 notification tone	Displays the Visual Information Bar with reduced brightness.
2	2 notification tones	Displays the Visual Information Bar at normal brightness.
